F&D F3800X User Manual

6
1
2
3
4
5
6
7
8
9
10
12
11
1. AUX L/R input
2. DVD F.R/F.L input
3. DVD S.R/S.L input
4. DVD SW/Center input
5. Speaker front right output
6. Speaker front left output
7. Speaker center output
8. Speaker rear right output
9. Speaker rear left output
10. Power switch
11. FM antenna
12. Power cable
System connection
7
Instruction of rear board
Output Power(RMS)：30W+10WX5
Speaker Unit:
Satellites: 3”
Subwoofer: 5.25”
Frequency Response：
Satellites: 40Hz-125Hz
Subwoofer: 120Hz-20KHz
S/N Ratio：≥70dB
Separation：≥40dB
Power:220V-240V AC 50/60Hz 0.32A
Unit size：
Satellites: W115XD104XH176mm
Subwoofer: W193XD282XH298mm
Specifications

F&D F3800X Specifications

General

Output Power	80W
Subwoofer	Yes
Satellite Speakers	Yes
Bluetooth	Yes
Signal to Noise Ratio	≥ 70dB
Separation	≥ 40dB
Remote Control	Yes
Configuration	5.1
Subwoofer Output Power (RMS)	30W
Satellite Output Power (RMS)	10W x 5
USB	Yes
FM Radio	Yes
Display	LED
Input Sensitivity	500mV
Input Impedance	10KΩ
Power Supply	AC 220V - 240V / 50/60Hz
