Fantec SQ-X2RU3e - Page 9

8
JBOD MODE(Single):
The normal Mode (Just a Bunch of Disks) storage policy enables each hard drive to be
seen separately as one drive. JBOD storage policy is for a standalone (non-cascaded)
Storage Processor or the top-level node of a cascaded configuration, but not for
subordinate nodes. In a JBOD configuration, each physical drive is directly exposed.
Drive A
Drive B
FANTEC SQ-X2RU3e
Port 0 Port 1
Volume B
Volume A
Drive A
Drive B
FANTEC SQ-X2RU3e
Port 0 Port 1
Volume B
Volume A
Equal hard drives
Unequal hard drives
