Fantech RVF 4XL - EC Motor Control and Wiring; Building Management System Connection (EC Motors); External Motor Speed Controller (EC Motors)

7
Figure 6 – Models: RVF4XL-EC, RVF6XL-EC, RVF8XL-EC, RVF10-EC
0 10
5
GRN/YELLOW
(GROUND)
BLUE WIRE
BLACK WIRE
L
N
GRD
FIELD WIRE
WHITE (LOW
VOLTAGE - TACH)
BLUE (LOW
VOLTAGE - GND)
YEL (LOW
VOLATAGE 0 -10 V
RED (LOW
VOLTAGE +10V)
Alternate Control Options: Products Containing EC Motors
Connection to Building Management System
Green Black White
Red (+) 10VDC Yellow Blue(-) GRD CTRL 0-10V/PWM
White TACH OUT
Motor
Green Black or Brown BlueBlue
Power
Control
Green Black White
Red (+) 10VDC Yellow Blue(-) GRD CTRL 0-10V/PWM
White TACH OUT
Motor
Green Black or Brown BlueBlue
Power
Control
1 2 3 4 5
U - Supply
Aux. switch 24V
MTP10 - Potentiometer
120V Supply
External Motor Speed Controller
Figure 7
Figure 8
