76
77
Seat Rail Binder
~25 – 40 Nm
~221 – 354
in-lb
Seatpost Collar Binder ~6 Nm 53 in-lb
CRANKSET, BOTTOM BRACKET AND PEDAL AREA
Component Newton Metre Inch-Pounds
Pedal into Crank 35 Nm (min) 310 in-lb (min)
Bottom Bracket Bearing Cups
(Ungreased) 25 Nm – 30 Nm 221 – 265 in-lb
Bottom Bracket Bearing Cups
(Greased) 20 Nm – 25 Nm 177 – 221 in-lb
Crank Bolt Screws 40 Nm 354 in-lb
Chainring Bolts
12 Nm 106 in-lb
HANDLEBAR, BRAKE LEVER, SELECTOR AND SHIFT CONTROL AREA
Component
Newton Metre Inch-Pounds
Brake Lever
(Flat Bar Type)
6 Nm – 10 Nm 53 – 88 in-lb
Shift Lever
(Thumb Trigger Type) 3 Nm – 5 Nm 27 – 44 in-lb
Shift Lever
(Twist Grip Type) 1.5 Nm – 2.5 Nm 13 – 22 in-lb
Selector Bolts 1.5 Nm 13 in-lb
Handlebar Grip Bolts
(Minimal torque needed to stop any
grip rotation or movement)
DISC BRAKE SYSTEM
Component Newton Metre Inch-Pounds
Disc Rotor To Hub
(M4 x 8mm bolts) 2 Nm – 4 Nm 18 – 35 in-lb
Caliper Mount 6 Nm – 8 Nm 53 – 71 in-lb
ACCESSORIES
Component Newton Metre Inch-Pounds
Fender Locknuts 5 Nm 44 in-lb
Kickstand Binder Bolt 20 Nm 177 in-lb
Front Rack
Rack Mount Cap Screws on Downtube 5 Nm 44 in-lb
Headtube Rack Mount Screw 10 Nm 88 in-lb
Rear Rack
All Mounting Bolts 5 Nm 44 in-lb
BATTERY
Component Newton Metre Inch-Pounds
Battery Set Screws
(Check that battery does
not slide with the applied torque)
1.5 Nm 13 in-lb
IX. TORQUE SPECIFICATIONS IX. TORQUE SPECIFICATIONS
