Turntable Installation
Counter-top Installation
Hub (underside)
Glass tray
Tu
Turntable shaft
a. Never place the glass tray upside down.
The glass tray should never be restricted.
b. Bothglasstrayandturntableringassembly
must always be used during cooking.
c. All food and containers of food are always
placed on the glass tray for cooking.
d. If glass tray or turntable ring assembly
cracks or breaks, contact your nearest
authorized service center.
Remove all packing material and accessories.
Examine the oven for any damage such as
dents or broken door. Do not install if oven is
damaged.
Cabinet:Removeanyprotectivelmfound
on the microwave oven cabinet surface. Do
not remove the light brown Mica cover that
is attached to the oven cavity to protect the
magnetron.
1. Select a level surface that provide enough
open space for the intake and/or outlet vents.
A minimum clearance of 3.0 inches (7.5cm) is
required between the oven and any adjacent
walls. One side must be open.
(1) Leave a minimum clearance of 12 inches
(30cm) above the oven.
2) Do not remove the legs from the
bottom of the oven.
(3)Blockingtheintakeand/oroutletopenings
can damage the oven.
(4) Place the oven as far away from radios
and TV as possible. Operation of
microwave oven may cause interference
to your radio or TV reception.
2. Plug your oven into a standard household
outlet.Besurethevoltageandthefrequency
is the same as the voltage and the frequency
on the rating label.
WARNING – Do not install oven over
a range cook-top or other heat-producing
appliance. If installed near or over a heat
source, the oven could be damaged and the
warranty would be void.
3.0 inch(7.5cm)
12 inch(30cm)
OPEN
