T. Reconnect the vehicles battery. Prime the fuel system. according to owners manual.
Note: Secure all fuel lines with cable ties. Cable ties are an economical way to prevent the
possibility of problems occurring!
R. Reconnect the filler neck and overflow tubes from the truck by tightening the clamps
S. Reinstall fuel tank. Torque hanger bolts to factory specifications. If need be, cover the return line with
spare tubing or similar to protect fuel line from rubbing on the trimmed fiberglass shell. Route FASS
fuel line to prevent pinching.
Possible Variations
Clamps will be located at both ends
Clamps will be located at the tank.
Some applications have an integrated overflow/inner tube assem-
bly. If so, then make sure the inner tube does not hang-up in the
tank.
Step 5: re-installing Fuel Sending Unit & Connecting
sump
