Titanium Series
Installation
Step 1: Install Electrical Harness
Step 2: Prepare Suction and Return Lines
Step 3: Mount Fuel System
Step 4: Install Fuel Line
Step 5: Check Installation
95 or 165 GPH
16-18 PSI (Approximately)
A fuel pressure gauge is highly recommended to identify fuel filter life and to prevent engine damage!
‘R’
Fuel Return to Tank
“E”
To Engine
Serial Number Location
‘G’
Fuel Pressure
‘T’
Fuel Inlet
Electric Heater
Port
“H”
Coolant Heater
2nd
Electric Heater Port
To Next Page
