96"
(244 cm)
68"
(173 cm)
Wall
Center of Board
Plumb Line 
from Face
of Board 
to Floor
Throwing 
or Toe Line
Floor
Throwing Distance
75
5
/ 8 "
(192 cm)
5
1
/
2
"
(14 cm)
68"
(173 cm)
Floor
Wall Stud Marking for Mounting Screw
Power Installation
The dartboard is designed to be powered by an AC to 9V DC, 800 milliamp (minimum)
adapter, with the DC plug polarity configured as positive (+) outside, and negative (-) center.
To connect by adapter, plug the DC plug into the DC power jack and the AC plug into an
electrical outlet.
Use of Transformer:
1. The board is not intended for children under the age of 3 years old.
2. The board must only be used with the recommended transformer.
3. The transformer is not a toy.
4. Disconnect from transformer before cleaning.
Protective Film
This electronic dartboard has a clear protective film over the entire display area and button
area to prevent scratching during shipping. Remove this film for easier reading of the display.
To remove, simply lift edge, peel off and discard.
Mounting
