Fatal1ty Z270 Professional Gaming i7 Series
underbolt AIC
Connector
(5-pin TB1)
(see p.1, No. 26)
1
Please connect a underbolt™
add-in card (AIC) to this
connector via the GPIO cable.
AURA RGB LED Header
(4-pin RGB_LED1)
(see p.1, No. 22)
RGB header is used to connect
RGB LED extension cable which
allows users to choose from
various LED lighting eects.
12V GRB
1
