143
DataType
bits
Description
BOOL
---
1
Boolean
SINT
---
8
Single integer
INT
---
16
Integer
DINT
---
32
Double integer
REAL
---
32
Float number
STRING
LEN
Length of string
DATA
Character data of string
COUNTER
PRE
32
Preset value
ACC
32
Accumulatedvalue
CU
1
Count up flag
CD
1
Count down flag
DN
1
Done flag
OV
1
Overflowflag
UN
1
Underflowflag
TIMER
PRE
32
Preset value
ACC
32
Accumulatedvalue
EN
1
Enable flag
TT
1
Timing flag
DN
1
Done Flag
AB:1769_DI16:I:0
Fault
32
Data
16
Data of DI16
AB:1769_DI32:I:0
Fault
32
Data
32
Data of DI32
AB:1769_DO16:O:0
Data
16
Data of DO16
AB:1769_DO32:O:0
Data
32
Data of DO32
2.7.1.3 Connecting to HMI
Configuring IP Address on PLC
The application RSLinx Classic (ver. 3.51) was used to configure the IP address on the
device.
On the PLC device, make sure the switch on the main module is not set to the RUN
setting.
Open RSLinx Classic and connect to the PLC either with a USB-Serial cable or through
the local network. To connect to PLC via the local network, follow the steps below.
In the Communications menu tab, select Configure Drivers. Select EtherNet/IP Driver
and press ‘Add New’. Select “Your Network Interface Card” and press OK. Start the
