FATEK P5070N - Page 219

219
Stop Bit
1
Parity
Odd
or even, no
PLC Station No.
1
1-90 DirectNET, K
sequence
1-247 Modbus RTU
Communication Method
K sequence (slave),
DirectNET
(master/slave),
Modbus
2.14.1.2 Memory Resource Review
Device
Data bit
Data format
Max.
Min.
Description
GX
1
OOOO
3777
0
Global Input Bits
GY
1
OOOO
3777
0
Global Output Bits
X
1
OOOO
1777
0
Input Bits
Y
1
OOOO
1777
0
Output Bits
C
1
OOOO
3777
0
Control Relays
S
1
OOOO
1777
0
Stage Status Bits
T
1
OOO
377
0
Timer Status Bits
CT
1
OOO
777
0
Counter Status Bits
SP
1
OOOO
1777
0
System Status Bits
V
16
OOOOO
77777
0
V Memory
2.14.1.3 Connecting to HMI
Configuring the PLC
1. openDSLaunch 5, click ApplicationsDirectSOFT 5 Programming on the left side.
