Connection diagram
Camcorder or Webcam using HDMI or SID cable to connect to Video Capture Device
Video Capture Device using USB Cable to connect to PC or Notebook Computer
PC or Notebook Computer have 3 ways to connect to Scoring Machine
1. Using ComPort RS422 DB9 Cable & ComPort to USB device to connect (Wire)
2. Using ComPort RS422 Bluetooth Adapter (Wireless - Bluetooth)
3. Using ComPort RS422 to Wifi Communicator (Wireless - Wifi)
USB cable
HDMI or SDI
Cable
RS422 Cable
Bluetooth SignalWifi Signal
