4. How to operate
2. Seat operation (reclining adjustment / seat separation for rear-facing)
Attention
Seat reclining can be adjusted up to 170 ◦ degrees via 3 step. Desired angle can be adjusted by
lifting up seat reclining lever ① as shown by arrow. Seat reclining can be adjusted up to 3 levels
for both of forward-facing and rear-facing.
1step : Seat mode 2step : Rest mode 3step : Sleep mode
Seat of this stroller can be separated
and available for both forward-facing
or rear-facing position. Seat can be
separated by pressing seat separation
button ® on the right and left side of
t
he safety guard and pull it to upward
direction.
When adjusting seat reclining angle, make sure to use it after locking the break.
3. Footrest adjustment / safety guard adjustment
Press the footrest adjustment button ①
located at both ends of both footrest
and desired angle adjustment can be
done via 8 step.
Safety guard can be opened and used
as shown in arrow ②.
