FUZ2 -A/-B/-C/-CX/-G/-L
Assembly instructions
TST
FEIG ELECTRONIC GmbH
Page 40 of 96
TST_FUZ2-A-B-C-CX-G-L_Montageanleitung_EN_22.docx
6.4.2 Electrical resistance safety edge
45
44
43
42
41
Spiral cable
Junction
box
8K2
43
44
41
42
Slack rope
switch
optional slip
door switch
brown
white
Outside
white
Inside
brown
Jumper J 800 is
located to the left
and behind terminal
61 - 62
1 3
J800 = 1-2
8,2K
1,2K
J800
Figure 19: Connection of an electrical resistance safety edge
