Feig Electronic TST FUZ2-C User Manual

TST
Assembly instructions
FUZ2 -A/-B/-C/-CX/-G/-L
FEIG ELECTRONIC GmbH
Page 63 of 96
TST_FUZ2-A-B-C-CX-G-
L_Montageanleitung_EN_22.docx
8.2 Editing a selected parameter
8.3 Exit parameter operation mode
Keep the STOP button pressed for approx. 3 seconds in
order to leave the parameter mode and change to the
door mode. The door operation is active when the
display shows for example:
FEIG ELECTRONIC
xxxx Zyklen
_Eu_
8.4 Execute a reset
+ + press for approx. 3 seconds.
8.5 Entry into the extended parameter configuration mode
In order to reach the extended parametrization mode, a
password must be entered in advance. The following
parameter must be set for this:
P: Passwort |
999= 0001 #
P.999
P.999 = 2 (extended start up mode)
P: Passwort |
999= 0001✓#
0001
P: Passwort |
999= 0002?#
0002
P: Passwort |
999= 0002✓#
P.999
1.
By briefly pressing the STOP key on the membrane
keypad, the cursor moves to the right to the stored value
(the parameter is opened) or the preset value is
displayed.
P: Offenhalt1 |
010= 10 s
P.010
P: Offenhalt1 |
010= 10✓s
10
2.
The parameter value is increased with the OPEN button
and reduced with the CLOSE button.
If the value has not yet been saved, a question
mark is displayed after the number or the
decimal point flashes.
P: Offenhalt1 |
010= 9?s
9
3.
If the STOP key is only pressed briefly, the set value
is not saved and the value is changed to the originally
stored value, i.e. the original value is displayed.
P: Offenhalt1 |
010= 10✓s
10
If you keep the STOP key pressed until the check
mark is displayed or the decimal point no longer flashes,
the changed value is saved.
P: Offenhalt1 |
010= 9✓s
9
4.
If you now press the STOP key briefly, you change
to the display of the parameter name or the cursor jumps
back to the parametrization.
P: Offenhalt1 |
010= 9 s
P.010

Feig Electronic TST FUZ2-C Specifications

General

Brand	Feig Electronic
Model	TST FUZ2-C
Category	Controller
Language	English
