FUZ2 -A/-B/-C/-CX/-G/-L
Assembly instructions
TST
FEIG ELECTRONIC GmbH
Page 68 of 96
TST_FUZ2-A-B-C-CX-G-L_Montageanleitung_EN_22.docx
10.3 … with light curtain TST LGB
Activating the TST LGB application
The application automatically sets several of the necessary function dependent parameters.
1. Set application parameter A.480 to "1".
2. Automatic range query: Set the real light curtain distance per
parameter P.44A in steps of 0.5 m.
The range must be adjusted according to the door
width.
Open the door completely!
If the light curtain is covered, the adjacent error
message will appear and the teach-in of all end
positions must be restarted.
Zur Aufpos. à
Hindernis T75
E

1

0

5

3. Start the synchronisation by briefly pressing the STOP-key.
! Synchron. !
I615 LL angef.
I

615
SYNC:
4. Open the door completely by pressing the OPEN-key.
Zur Aufpos. à
I615 LL angef.
SYE

o

If the door moves in the wrong direction: wrong motor
rotary field, change parameter P.130 from 1 to 0 (change
direction of rotation). If the door does not move, the
motor lacks power. With the aid of the boost
(performance increase at low speeds) the motor can be
supplied with an increase in power. (see Chapter 10.5) if
necessary, check that the brake is released.
Zur Aufpos. à
Folie STOP
E

05o

SYNC:
5. Pressing the STOP-key for approx. 3 seconds to save the
OPEN position.
Zur Aufpos. à
0 Übernahme mit
S

Y

E

o

6. Press STOP-key.
Zur Aufpos. à
Folie STOP
S

Y

E

o

E

050
Zur Aufpos. OK
0
S

Y

E

o

Light line alignment is being requested.
LGx Qual. Test
S

Y

E

o

7. Start automatic teach-in of CLOSE-position by pressing the
CLOSE-key.
! Synchron. !
0 Start mit
S

Y

E

u

Automatic teach-in of the CLOSE position.
Door closes.
The detection zone of the light curtain must remain free
otherwise the correction drive will be terminated and the
synchronisation of the light curtain starts from the
beginning.
Suche Si-Leiste
xxx Auto zu
S

Y

c

L

