Feig Electronic TST FUZ2-C User Manual

FUZ2 -A/-B/-C/-CX/-G/-L
Assembly instructions
TST
FEIG ELECTRONIC GmbH Page 86 of 96 TST_FUZ2-A-B-C-CX-G-L_Montageanleitung_EN_22.docx
No.
Description
Possible reason for error
F.823
Wrong parameter setting input
3 of mobile unit
• The device which is connected to input 3 of the mobile unit does not fit to the settings
• Check Parameter P.F3F
F.824
Wrong parameter setting input
4 of mobile unit
• The device which is connected to input 4 of the mobile unit does not fit to the settings
• Check Parameter P.F4F
F.831
Disturbed input 1 of mobile unit
TST FSx
• The input 1 of the mobile unit is disturbed
• The connection to the device is interrupted
F.832
Disturbed input 2 of mobile unit
TST FSx
• The input 2 of the mobile unit is disturbed
• The connection to the device is interrupted
F.833
Disturbed input 3 of mobile unit
TST FSx
• The input 3 of the mobile unit is disturbed
• The connection to the device is interrupted
F.834
Disturbed input 4 of mobile unit
TST FSx
• The input 4 of the mobile unit is disturbed
• The connection to the device is interrupted
F.841
Frequency error on input 1 of
mobile unit
• The connected optical safety edge is faulty
F.843
Frequency error on input 3 of
mobile unit
• The connected optical safety edge is faulty
F.851
Max. Number of allowed
Reversings, because of bad
WiCAB radio, exceeded.
The radio connection interrupts during door drive for a short time
F.852
Communication error between
TST FSx and controller
This error occurs when the controller looses RS485 communication for min. 1 second with the stationary unit of the
radio strip TST FSx. Possible causes are:
• The stationary unit is broken
• The stationary unit is not or wrong connected
F.853
TST PE_FSBS operating
voltage too low
The operating voltage of encoder TST PE_FSBS is too low (less than 8V) As a result, the calculation of the position
must be terminated.
F.854
Faulty wiring between
stationary unit and controller
Number of trips permitted (P.F02) due to breakage or short circuit on a line between stationary unit and door
controller.
F.856
Communication error between
mobile and stationary unit
This error occurs if the mobile unit and the stationary unit of the radio control unit could not establish radio
communication for at least 1 second. Possible causes are:
• No mobile unit in radio range
• The battery of the mobile unit is empty or not connected
• The antenna of the stationary unit is not connected or missing
• Mobile unit or stationary unit are defective
F.857
Battery empty
• The battery voltage is under the limit set with Parameter P.F0B
• The battery voltage of the mobile unit is to low
• Use new battery and set back battery capacity to 100% by pressing the stop key for long time in P.F09.
• To deactivate this error message you can set P.F09 and P.F0B to 0
F.859
Software Version
The software versions of the stationary and the mobile unit are not compatible. No safe trip possible.
