Dimensions board set (L x W x H):
approx. 270 x 195 x 150 mm to frame with quick release
incl. heatsink
excl. extension boards as TST RFUxK or TST RFUxCom
Controller variants -A / B
182 x 328 x 102 mm (with spacers)
Controller variants -C / -CX
Controller variants
-CGH / -CXGH / -LGH
210 x 430 x 200 mm
incl. heatsink, brake resistor & wall mounts
excl. cable entries (L +20 mm) and main switch (H +35 mm)
Dimensions plastic housing
(H x W x D)
approx. 430 x 210 x 200 mm
incl. heatsink, brake resistor & wall mounts
excl. cable entries (L +20 mm) and main switch (H+ 35 mm)
Dimension steel or stainless steel
housing
approx. 300 x 476 x 218 mm
approx. 400 x 676 x 218 mm
approx. 600 x 676 x 218 mm
excl. cable entries (L +20 mm) , main switch and
emergency stop button (H+ 35 mm)
Hygiene housing dimensions
approx. 444 x 549 x 210 mm
excl. cable entries (L +20 mm) , main switch and
emergency stop button (H+ 35 mm)
vertically via the wall bracket on the housing bottom
Supply voltage over
L, N, PE
230 V
AC
10%, 50...60 Hz
permissible range: 110...240 V ± 10% / 50...60 Hz
Protection: 16 A K-characteristic
Controller idling current
max. 30 W when fully configured
External power supply (depending
on network): Terminal L1
According to supply voltage to terminal L
(secured on the circuit board: F200 / 4AT)
Control voltage / external supply 2
24 V
DC
regulated (10% at nominal voltage 230 V)
Controller variant -A: max. 250 mA
Controller variants -B/-C/-CX/-CGH/-CXGH/-LGH: max.
500 mA
ncl. optional plug-in modules. Fuse protected by means of
self-resetting semiconductor fuse.
Short-circuit protected by central switching regulator.
Control voltage / external supply 3
for electronic limit switches and Safety edge
Nominal value 11.3V / max. 130mA
Controller inputs
Inputs 1 – 10 in
Controller variants
-C / -CX / -CGH / -CXGH / -LGH
Inputs 1 – 9 in
Controller variant -A
24 VDC / typ.15 mA, max 26 VDC / 20 mA.
all inputs are potential free to join or:
< 2 V: inactive à logical 0
>10.5 V: active à logical 1
min. Duration of input control commands: > 100 ms
Galvanic isolation using on-board opto-couplers
Input IN10
Controller variant -B
Evaluation for slip door switch with 8.2 kΩ termination
resistor or is used as a second safety edge monitor.
Serial interface
RS485 A and B
only for electronic limit switches
RS485 level, terminated in 100 Ω
Safety chain / Emergency STOP
Terminals: E-Stop ext.31/32 and
41/42
all inputs must be connect free of potential
Contact rating: 26 V
DC
/ 120 mA
in case the safety chain is interrupted, the drive cannot be
moved, not even under Deadman conditions
Not jumpered from the factory
For electrical safety edges with 1.2 or 8.2 kΩ terminating
resistor and for dynamic optical systems
