Mounting Instructions
Check that black, white and ground wire are extending from the
xture. Before wiring the xture to the power supply, turn off
the electricity at the fuse or circuit breaker box. Fixture must be
grounded to avoid potential electric shock.
1. Mount arm assembly (sold by others) in desired location rmly.
Pole Mount:
2. Take off the grommet.
2. Feed supply wires up through mounting arm,
use wire nuts (CC) to connect neutral, line and
grounding wires (see step 4). Push the wires and
connectors into arm.
3. Install conduit tting (not supplied) on the
xture, feed the power supply wires into
the xture / conduit tting and connect with
xture wires. Attach conduit into the xture.
1. Place the xture end (shown below) onto
the wall at the desired location and mark
the position for the mounting screws. Drill
three holes as required. Either pilot holes
for the screw or holes for anchors. Install
the anchors as appropriate.
4. Attach the xture housing to the
wall as appropriate.
3. Tighten the 2 set screws on the xture into the
mounting pole rmly.
Carefully unpack and
unwrap fixture
Installing the fixture
Mounting Options
(Refer to page 7 for the wiring diagram)
1 2
3
CAUTION: TURN OFF THE CIRCUIT BREAKER AT
THE ELECTRICAL PANEL BEFORE INSTALLING THE
FIXTURE IN ORDER TO PREVENT POSSIBLE SHOCK.
Wall Mount:
1.5” (38.1mm)
2.5” (63.5mm)
