Appendix A // Wire & Hose Lengths
MODEL FRAME SIZE PART MODEL2 LENGTH QTY
Shimano Di2
w/RS910
48CM-58CM
E WIRE EW-SD50I
1200MM 1
750MM 1
300MM 3
850MM 2
48CM
LEFT LEVER / FRONT BRAKE
L/ST-R9180(L)-70SS 750MM 1
R/ST-R9180(R)-34SS 1550MM 1
51CM
LEFT LEVER / FRONT BRAKE
L/ST-R9180(L)-70SS 800MM 1
R/ST-R9180(R)-34SS 1600MM 1
54CM
LEFT LEVER / FRONT BRAKE
L/ST-R9180(L)-70SS 800MM 1
R/ST-R9180(R)-34SS 1650MM 1
56CM
LEFT LEVER / FRONT BRAKE
L/ST-R9180(L)-70SS 800MM 1
R/ST-R9180(R)-34SS 1700MM 1
58CM
LEFT LEVER / FRONT BRAKE
L/ST-R9180(L)-70SS 850MM 1
R/ST-R9180(R)-34SS 1700MM 1
Shimano Di2
w/ Standard
Junction A
48CM-58CM
E WIRE EW-SD50I
1200MM 1
250MM 1
300MM 1
750MM 1
850MM 2
48CM
LEFT LEVER / FRONT BRAKE L/HD-T910-70SS 750MM 1
RIGHT LEVER / REAR BRAKE R/HD-T910-34SS 1550MM 1
51CM
LEFT LEVER / FRONT BRAKE L/HD-T910-70SS 800MM 1
RIGHT LEVER / REAR BRAKE R/HD-T910-34SS 1600MM 1
54CM
LEFT LEVER / FRONT BRAKE L/HD-T910-70SS 800MM 1
RIGHT LEVER / REAR BRAKE R/HD-T910-34SS 1650MM 1
56CM
LEFT LEVER / FRONT BRAKE L/HD-T910-70SS 850MM 1
RIGHT LEVER / REAR BRAKE R/HD-T910-34SS 1700MM 1
58CM
LEFT LEVER / FRONT BRAKE L/HD-T910-70SS 850MM 1
RIGHT LEVER / REAR BRAKE R/HD-T910-34SS 1700MM 1
Mechanical
48CM-51CM
Rear shfiter aduster to rear der Cable B 1380MM 1
Shifter from extensions to adjusters Cable A 500MM 2
Front shifter adjuster to front der Cable C 920MM 1
54CM-56CM
Rear shfiter aduster to rear der Cable B 1420MM 1
Shifter from extensions to adjusters Cable A 500MM 2
Front shifter adjuster to front der Cable C 960MM 1
58CM-60CM
Rear shfiter aduster to rear der Cable B 1040MM 1
Shifter from extensions to adjusters Cable A 500MM 1
Front shifter adjuster to front der Cable C 1500MM 2
SRAM
Wireless /
Mechanical
48CM
LEFT LEVER / FRONT BRAKE DB-S-900-A1-70SS 750MM 1
RIGHT LEVER / REAR BRAKE DB-S-900-A1-34SS 1550MM 1
51CM
LEFT LEVER / FRONT BRAKE DB-S-900-A1-70SS 800MM 1
RIGHT LEVER / REAR BRAKE DB-S-900-A1-34SS 1600MM 1
54CM
LEFT LEVER / FRONT BRAKE DB-S-900-A1-70SS 800MM 1
RIGHT LEVER / REAR BRAKE DB-S-900-A1-34SS 1650MM 1
56CM
LEFT LEVER / FRONT BRAKE DB-S-900-A1-70SS 800MM 1
RIGHT LEVER / REAR BRAKE DB-S-900-A1-34SS 1700MM 1
58CM
LEFT LEVER / FRONT BRAKE DB-S-900-A1-70SS 850MM 1
RIGHT LEVER / REAR BRAKE DB-S-900-A1-34SS 1700MM 1
