Fender The Bends - Page 2

1
2
3
74
1. Bypass Footswitch
2. Jewel Indicator
3. Output Jack
4. Blend
5. Drive
6. Recovery
7. Level
8. Input Jack
9. Low Battery Indicator
10. LED Kill Switch
11. DC Power Connector
10
11
LEDs
9V DC
INPUT
8
5 6
THE BENDS
BLEND
COMPDRY
SLOWFAST
DRIVE RECOVERY
LEVEL
9
