FENDT IDEAL 9 Workshop Service Manual

1.4.10 Hydraulic system specifications
System
IDEAL 7 IDEAL 8 IDEAL 9
Type Load sensing
Pump type Piston
Pump displacement 115cc (7.0 cu in) 147cc (9.0 cu in)
Accumulator precharge
IDEAL 7 IDEAL 8 IDEAL 9
Header lift small accumulator
(AC1a)
60 bar (870 psi)
Header lift large accumulator
(AC1b)
40 bar (580 psi)
Feeder pitch accumulator (AC2) 27.6 bar (400 psi)
Transmission accumulator (AC3) 10 bar (145 psi)
Park brake accumulator (AC4) 10 bar (145 psi)
Header lift cylinders
IDEAL 7 IDEAL 8 IDEAL 9
Piston diameter 70 mm (2.8 in) 80 mm (3.1 in)
Closed length 1127 mm (44.4 in) 1127 mm (44.4 in)
Stroke 835 mm (32.9 in) 835 mm (32.9 in)
Unloading auger cylinder
IDEAL 7 IDEAL 8 IDEAL 9
Piston diameter 60 mm (2.4 in)
Closed length 1100 mm (43.3 in)
Stroke 780 mm (30.7 in)
Power steering cylinders (double acting)
IDEAL 7 IDEAL 8 IDEAL 9
Piston diameter 80 mm (3.1 in)
Stroke 310 mm (12.2 in)
Unloading auger cylinder
IDEAL 7 IDEAL 8 IDEAL 9
Piston diameter 170 mm (6.7 in)
Closed length 692 mm (27.2 in)
Stroke 205 mm (8.1 in)
GUID-918916CC-A8A6-424A-B86F-F9F05D75EBE4 [V3]
1. General
1-72 IDEAL Series Combine
79037318C
