BEFORE OPERATING THE
MACHINE
USE ONLY SHARP DRILLS OF THE
FOLLOWING TYPES
Fig.B
Concrete/masonry
|
Hard metal
Metal
|
HSS
Wood
|
HSS
MOUNTING ACCESSORIES
Fig.C
Prior to mounting an accessory always unplug the
tool.
Placing and removing bits
In addition to bits the machine can also hold screw bits
with a hexagonal shaft.
• Loosen the chuck by rotating the handgrip (A).
• Insert the drill/bit into the chuck.
• Tighten the chuck so that the drill/bit is firmly
clamped.
OPERATION
THE ON/OFF SWITCH
Fig.D
• Switch the machine on by pressing the triggerswitch
(A). When you release the triggerswitch (A) the
machine will turn off.
SWITCH-LOCK
• You can lock the On/Off switch by pressing the
triggerswitch (A) and then pressing knob (B). Release
the switch-lock by pressing the triggerswitch (A)
shortly.
SPEED-CONTROL
• The rotation-speed can be continuously adjusted
between 0 and 2500 rotations per minute by
pressing the switch (A) deeper or less deep.
ADJUSTING OF THE MAXIMUM
ROTATIONSPEED
• Switch the machine on by pressing triggerswitch (A).
• Lock the triggerswitch (A) by pressing knob (B).
• Adjust the speed by turning the small wheel (C) to
the desired maximum rotation speed.
SWITCHING THE DIRECTION OF
ROTATION
• Direction of rotation counter-clockwise: shift
switch (D) to “L”.
• Direction of rotation clockwise: shift switch (D) to
“R”.
SWITCH FOR PERCUSSION DRILLING
Fig.E
With the switch on top of the machine you can select
normal or percussion drilling.
• Slide the switch to the “Drill” symbol for normal
drilling.
• Slide the switch to the “Hammer” symbol for
percussion drilling.
MALFUNCTION
Below we have listed a number of possible causes and
corresponding solutions in case the machine does not
function as it should:
1. Excessive sparkling
• This usely indicates dirt in the motor or worndown
carbon brushes.
Bring your percussion drill to your Ferm-dealer.
2. The percussion drill is overheating
• The ventilationslots are covered with dirt.
Clean them with a dry cloth.
• The percussion drill is overloaded.
Use the machine for work for which it is ment to be.
Replace the drill for a sharp one or sharpen the drill by
using a benchgrinder and a twist drill grinding
attachment.
• The motor is defect.
Bring your percussion drill to your Ferm-dealer for
repairance.
Ferm 5
