Ferm FSMC-200/150 - Page 2

Fig. A.
Fig. B.
Fig. C.
A
B) 1-1.5 mm
C) 1-1.5 mm
A
2
6
57 43
1
2 Ferm
Ferm 55
2
5 43
1
EXPLODED VIEW
SPARE PARTS LIST FSMC-200/150
REF.NR. DESCRIPTION FERM NR.
001 SWITCH 206403
002 SUPPORT 206431
003 COVER GLASS 206401
004 COVER GLASS HOLDER 206132
005 WATER TANK 206442
- GEAR 205450
