ACCESSORIES
CONTROL PANEL
Two series of panels are available: for installation on the machine and for remote controlled wall mounted instal-
lation. Each of the series includes three types of control: switch, basic thermostat and upgraded thermostat.
FUNCTIONS
The various functions available are listed below to allow the type of control model to be selected more quickly. These
functions are described in the following pages.
APPLICATION
Cabinet Remote control
FUNCTIONS
Switch
Basic
thermostat
Upgraded
thermostat
Switch
Basic
thermostat
Upgraded
thermostat
Main ON-OFF switch
••••••
Thermostat controlled temperature
•• ••
Set point variation by means of Economy button
••
Manual selection of fan speed
••••••
Automatic selection of fan speed
••
Manual SUM./WIN. mode selection on control
•• ••
Autom. SUM./WIN. mode selection on control
•• ••
Remote controlled SUM./WIN. mode selection
••
Main bank valve
•• ••
Electric heating element/auxiliary bank valve
••
ON/OFF/Continuous thermostat fan control
•• ••
Probe reading correction
•• ••
Configuration of unit - System with 2 pipes
••
Configuration of unit - System with 4 pipes
••
Configuration of unit - System with 2 pipes+Heat.el.
••
Heating element control
••••
Dead zone set-up
••
Bimetallic minimum temperature probe
••
General control of the unit
Temperature control
ventilation control
SUM./WIN. seasonal mode control
Functions configured during installation phase
Integration with accessories
Management of Valves/Electric heating elements
Tab.11
