ferrotec Temescal CV-6SLX User Manual

3.6 Control of Power Supply by a PLC-Based System Controller Section 3: Power Supply Operation
CV-6SLX User Manual 0101-8242-0, Rev. C
3-8
Figure 3-9 Remote Controller’s LOCAL Screen, Menu 1 Selected, Beam and Sweep Off
3.6 Control of Power Supply by a PLC-Based System Controller
3.6.1 Switching Main Power On/Off
To switch on three-phase input power to the power supply, set the HVPS front-panel’s main
power breaker to the ON position (i.e., all the way up). To switch off main input power, set the
main power breaker to the OFF position (i.e., all the way down).
Press to switch beam On/Off
Joystick. When Pwr Adjust is selected, push up/down to
increase/decrease beam power.
Press to select beam power control
as the joystick’s function
