System manual CECX / CAN option module CECX-F-CO
CECX-II 30-11
30.10 Technical data
Envirionmental conditions
Operating temperature: +5 °C bis +55 °C
Storage temperature: -40 °C bis 70 °C
Relative humidity of air: 10 % bis 95 % (nicht kondensierend)
Vibration resistance: Gemäß EN 61131-2:2007
Shock resistance: Gemäß EN 61131-2:2007
Interface to CPU module
Interface type: Media Independent Interface
Connection: CHAMP plug 30-pole
Power supply: 5 V
Module recognition: YES (Module given, YES/NO, no type recognized)
CAN interface
Baud rate: 125 kbit/s, 250 kbit/s, 500 kbit/s, 800 kbit/s, 1 Mbit/s
Terminating resistor: YES, can be bridged in plug
Galvanic isolation: NO
Connection: DSUB 9-pin connector plug
Signaling: 2 LEDs: yellow...transmit, green...receive
Mechanics
Structure: No casing; only front plate mounted on print
Protection class:
When the module is plugged into the CPU module, the CPU
module meets IP20
Weight: 27 g
