Modular valve terminal with integrated controller CPX-CEC-...
7
Functionality/functions Supported
Window All functions Yes
Editors (languages) Instruction list (IL) Yes
Structured text (ST) Yes
Sequential function chart (SFC) Yes
Function block diagram (FBD) Yes
Ladder diagram (LD) Yes
Continuous function chart (CFC) Yes
PLC
configuration
Settings Automatic calculation of addresses Adjustable
Check for overlapping addresses Yes
Save configuration files in project Yes
HW scan Yes
Status Yes
Diagnosis from target system Yes
Alarm
configuration
All functions Yes
Global
variables
All functions Yes
Library manager All functions Yes
Log All functions Yes
Functionality/functions Supported
Task configuration Append task Name Yes
Priority (0-31) Yes
1)
Cyclic Yes
Freewheeling Yes
Triggered by event Yes
Triggered by external event Yes
Watchdog Yes
Time
Sensitivity
Append program call Yes
1) If the priority is the same, the longer waiting time is decisive
