A. Notes on commissioning and service
A−21
Festo P.BE−CPX−CMA X−CONTROL−EN en 0908NH
A.3.2 Exchanging components
Nominal/actual comparison of the hardware configuration
With each new calculation of the controller, a nominal/actual
comparison between the current hardware configuration
(actual configuration) and the setpoint configuration is per
formed.
Setpoint configuration The setpoint configuration consists of the values for the
drive configuration parametrised by the user.
Actual configuration The actual configuration consists of values for
the hardware
components ascertained during the automatic hardware
recognition.
Exchange of a component
The CMAX identifies an exchange as specified in Tab.A/4.
Component
Component exchanged for component ...
of the same type and size of another type or size
Cylinder/drive
DGCI: Recognition based on serial
number of the measuring system
DGCI: Recognition based on length and
diameter information in the measuring
system
Other drives: recognition not possible Other drives: recognition not possible
Valve Recognition based on serial number Recognition based on type information
Measuring system
DGCI: Recognition based on serial
number
DGCI: Recognition based on length and
diameter information
Other measuring systems: recognition
not possible
Other measuring systems: recognition
of the design based on sensor inter
face, no length information.
Sensor interface Recognition based on serial number Recognition based on type information
Tab.A/4: Exchange of a component − recognition by the CMAX
