C. Configuration with CPX node
C−16
Festo P.BE−CPX−CMA X−CONTROL−EN en 0908NH
C.2 CPX−FB11 (DeviceNet)
General information on the CPX−FB11 are found in the de
scription on the P.BE−CPX−FB11−...
C.2.1 Configuring DeviceNet station properties (EDS)
When starting up a new DeviceNet station for the first time,
you must inform your configuration program about certain
properties of the station.
The features of the various slaves are usually administered by
the configuration program in a list or library e.g. EDS library
(EDS for electronic data sheets).
The following possibilities can be
used with the CMAX:
Install EDS files: modular EDS.
Parametrising of technology modules such as the CMA X is
only supported via modular EDS.
Manually enter the slave features (no parameter setting
possible).
Observe the notes in the manual for the CPX−FB11.
Source of supply for EDS files
Sources of supply Current EDS files and
picture files (icons) can be found in
the Internet under the following address:
è www.festo.com è Downloads è Download Area: Soft
ware, drivers and firmware è Enter string: Fieldbus GSD/
EDS or CMAX
