C. Configuration with CPX node
C−27
Festo P.BE−CPX−CMA X−CONTROL−EN en 0908NH
C.3 CPX−FEC
General information on the CPX−FEC can be found in the
description of the P.BE−CPX−FEC−....
Detailed information on operating the FST can be found in the
FST manual P.BE−FST...
C.3.1 Configuration
Use Festo Software Tools (FST 4.1 or higher) with the Hard
ware Configurator in order to configure your CPX terminal
with CPX−FEC.
To configure the CMAX, this must be in the catalogue of
the CPX configurator (CPX terminal / Technology modules /
CPX−CMAX...). You may require an FST software update for
this (CPX
configuration update):
è www.festo.com è Downloads è Download Area: Soft
ware, drivers and firmware è Enter string: FST
Caution
If you have connected a CPX terminal to your PC for con
figuration: Test projects and programs at first without ac
tive actuators or without compressed air.
You will then avoid damage in the test phase.
I/O configuration / CPX configuration
You can create the configuration in the following ways:
Nominal/actual comparison in the editor mode
Change to the online mode
Manual configuration with the Hardware Configurator
