Radar Training System, LabVolt Series
© Festo Didactic 20
•
•
•
List of Equipment
Qty Description
Model
number
1 RCS/ISAR Measurement Interface __________________________________________________ 581960 (9610-00)
1 RCS/ISAR Data Acquisition Interface _______________________________________________ 8122692 (9634-10)
1 Accessories for 8097-A __________________________________________________________ 8129037 (9688-D0)
Manual
Table of Contents of the Manual(s)
RCS and ISAR Measurement Training System (User Guide) (593911 (52792-E0))
1 Overview of the RCS and ISAR Measurement Training
2 Module Setup and Connections
3 RCS Measurement
The RCS pattern of an actual aircraft can be obtained by placing a reflective
scale model on top of the low-RCS rotating support of the RCS and ISAR
Measurement Training System.
Accessories for 8096-A.
Description
Manual
number
RCS and ISAR Measurement Training System (User Guide) _________________________________593911 (52792-E0)
