Optional Equipment Description
Dual-Trace Digital Storage Oscilloscope (Optional)
585695 (798-10)
The Dual-Trace Digital Storage Oscilloscope is a low-cost
oscilloscope that is ideally suited for general purpose use in any
classroom laboratory. Two low capacitance probes are included
with the unit.
Features & Benefits
Color, 17.8 cm (7 in) liquid crystal display
Multi-language, on-display menu
50 MHz bandwidth
1 GSa/s maximum sampling rate
10 ns/div to 50 s/div time base
2 mV/div to 10V/div vertical sensitivity
±3% accuracy
USB and RS 232 ports
Compact design
Light weight
Function Generator 5 MHz (Optional)
8125246 (9409-00)
Direct digital synthesized arbitrary function generator, perfect to
complement telecommunication or radar training systems.
Frequency Counter (0.1Hz - 2.4 GHz) (Optional)
8112877 (9416-00)
2.4 GHz frequency counters that is microprocessor controlled. Its LED
displays can provide up to nine digits of resolution using an external
time base with a 10 s gate time. The high accuracy, sensitivity, and
versatility of these counters make them an extremely valuable
instrument to complement telecommunication and radar training
systems.
