Festool CTL MINI Original Operating Manual

10
CTL MINI/MIDI
Symbol Significance
Warning! The machine may contain
hazardous dust!
Do not dispose of as domestic
waste.
Symbol Significance
Climbing prohibited
3 Technical data
Mobile dust extractors
Power consumption 400 - 1200 W
Max. appliance socket connected load EU 2400 W
CH, DK 1100 W
GB 240 V / 110 V 1800 W / 500 W
Max. suction capacity (air), extractor/turbine 95 m
3
/h / 222 m
3
/h
Max. vacuum, turbine 24000 Pa
Filter surface area 5000 cm
2
Suction hose D 27/32 mm x 3.5 m-AS
Length of the net cable 7.5 m
Sound pressure level as per EN 60704-2-1 /
Uncertainty K
72 dB(A) / 3 dB
Protection category IP X4
Container capacity CTL Mini 10 l
CTL Midi 15 l
Dimensions L x W x H CTL Mini 430 x 330 x 420 mm
CTL Midi 430 x 330 x 470 mm
Weight CTL Mini 8.8 kg
CTL Midi 9.1 kg
4 Machine features
[1-1] Suction power adjuster
[1-2] Appliance socket
[1-3] SysDoc
[1-4] Handle
[1-5] Intake opening
[1-6] Angle adapter
[1-7] Hose store
[1-8] T-LOC latch for Systainers
[1-9] Dust container
[1-10] Locking clip
[1-11] Switch
[1-12], [1-13] Brake
The specified illustrations appear at the beginning
of the Operating Instructions.
5 Intended use
Mobile dust extractor suitable for
– Extracting dust up to 1 mg/m³ according to dust
class ‘L’,
– Extracting water,
– Increased loads during commercial use,
according to IEC/EN 60335-2-69.
The user is liable for improper or non-
intended use.
6 Commissioning
WARNING
Unauthorised voltage or frequency!
Risk of accident
XThe mains voltage and the frequency of the
power source must correspond with the
specifications on the machine’s name plate.
XObserve country-specific regulations.

Festool CTL MINI Specifications

General

Input power	1200 W
Airflow	61.6 l/s
Capacity	- L
Filter surface	5000 cm²
Container capacity (dust)	10, 7.5 L
Product color	Black, Green, White

Weight and Dimensions

Depth	440 mm
Width	340 mm
Height	420 mm
Weight	8700 g
