10
CTL SYS
3 Intended use
Dust extractor suitable for
– Aspiration and extraction of dust with limit
values up to 1 mg/m³ corresponding to dust
class ’L’,
– for increased loads during commercial use,
according to IEC/EN 60335-2-69.
Dust extractor not recommended for continuous
aspiration and extraction of fine dust, such as
cement dust or filler.
The user is liable for improper or non-
intended use.
4 Technical data
Dust extractors
Power consumption 1000 W
Max. appliance socket connected load EU 1200 W
CH, DK 1300 W
GB 1400 W
Max. suction capacity (air), extractor/turbine 108 m
3
/h / 180 m
3
/h
Max. vacuum, turbine 200 hPa
Filter surface area 5357 cm
2
Suction hose D 27 mm x 3.0 m-AS
Length of the net cable 5.0 m
Sound pressure level as per EN 60704-2-1 /
Uncertainty K
67 dB(A) / 3 dB
Vibration value at the cleaning nozzle/
instability
<2.5 m/s
2
/ 1.5 m/s
2
Protection category IP X0
Container capacity 4.5 l
Dimensions L x W x H CTL SYS with storage box 396 x 296 x 270 mm
only CTL SYS 396 x 296 x 162 mm
Weight CTL SYS with storage box 6.9 kg
5 Machine features
[1-1] Dust extractor
[1-2] Storage box
[1-3] Extractor hose
[1-4] Handle
[1-5] Angle adapter
[1-6] T-LOC latch for Systainers
[1-7] Cold-device plug
[1-8] ON/OFF switch
[1-9] AUTO/MAN switch
[1-10] Appliance socket
The specified illustrations appear at the beginning
of the Operating Instructions.
6 Operation
WARNING
Unauthorised voltage or frequency!
Risk of accident
XObserve the specifications on the machine’s
name plate.
XObserve country-specific regulations.
6.1 Connecting dust extractor
WARNING
Risk of injury from tools starting up unex-
pectedly
XBefore switching on ensure that the connected
tool is switched off.
