D U R A D R I V E
15
GB
– Protect the battery pack from excessive heat > 50
°C or constant heat sources such as sunlight or
naked flames!
– Never use water to extinguish burning li-ion bat-
tery packs! Use sand or a fire blanket.
– Check the plug and the cable regularly and
should either become damaged, in order to avoid
a hazard, have them replaced by an authorised
after-sales service workshop.
– Always pull the mains plug out of the socket
when the charger is not in use.
–
Only for AS/NZS:
The tool shall always be sup-
plied via residual current device with a rated re-
sidual current of 30 mA or less.
2.4 Emission levels
Levels determined in accordance with EN 60745 are
typically:
Vibration emission value a
h
(vector sum for three
directions) and uncertainty K measured in accor-
dance with EN 60745:
The specified emissions values (vibration, noise)
– are used to compare machines.
– They are also used for making preliminary esti-
mates regarding vibration and noise loads during
operation.
– They represent the primary applications of the
power tool.
Increase possible for other applications, with other
insertion tools or if not maintained adequately. Take
note of idling and downtimes of machine!
3 Intended use
The drywall screwdriver is designed for the follow-
ing works:
DWC 18-2500
– Gypsum fibreboards on metal and wooden con-
structions - Drywall screws with milling ribs
– Chip boards/OSB on wooden constructions bis D
5 mm - Wood construction and chip board screws
up to dia. 5 mm
DWC 18-4500
– Gypsum plaster boards on metal profile rails
(≤ 0.88 mm) - Drywall screws with fine thread
– Gypsum plaster boards on metal profile rails
(≤ 2.25 mm) - Drywall screws, self-drilling
– Gypsum plaster boards on wooden constructions
- Drywall screws with coarse thread
Charger TCL 3
suitable for
– charging Festool battery packs: BP, BPS and
BPC (NiMH, NiCd, li-ion are recognised automat-
ically.)
– indoor use only.
The user is liable for improper or non-in-
tended use; this also includes continuous in-
dustrial operation.
4 Technical data
* Speed specifications with fully charged battery pack.
Further technical data on the charger and battery packs can be found on page 6.
Sound pressure level L
PA
= 78 dB(A)
Sound power level L
WA
= 89 dB(A)
Uncertainty K = 3 dB
Wear ear protection.
DWC 18-2500
a
h
= 2,8 m/s
2
K = 1,5 m/s
2
DWC 18-4500
a
h
= 3,5 m/s
2
K = 1,5 m/s
2
Cordless drywall screwdriver DWC18-2500 DWC18-4500
Motor voltage 18 V 18 V
Idle speed* 0 - 2500 min
-1
0 - 4500 min
-1
Torque (hard / soft) 7 / 18 Nm 5 / 14 Nm
Chuck 1/4 ’’ DIN 3126 / ISO 1173 1/4 ’’ DIN 3126 / ISO 1173
Weight (without battery pack) 1,1 kg 1,1 kg
Weight with depth stop (without battery pack) 1.2 kg 1.2 kg
Weight with magazine attachment (without
battery pack)
1.5 kg 1.5 kg
