DWC
13
GB
3 Intended use
The drywall screwdriver is designed for the follow-
ing works:
DWC 18-2500
– Gypsum fibreboards on metal and wooden con-
structions - Drywall screws with milling ribs
– Chip boards/OSB on wooden constructions bis D
5 mm - Wood construction and chip board screws
up to dia. 5 mm
DWC 18-4500
– Gypsum plaster boards on metal profile rails
(≤ 0.88 mm) - Drywall screws with fine thread
– Gypsum plaster boards on metal profile rails
(≤ 2.25 mm) - Drywall screws, self-drilling
– Gypsum plaster boards on wooden constructions
- Drywall screws with coarse thread
The user is liable for improper or non-in-
tended use; this also includes continuous in-
dustrial operation.
4Technical data
* Speed specifications with fully charged battery pack.
5 Machine features
Accessories shown or described are sometimes not
included in the scope of delivery.
The specified illustrations appear at the beginning
of the Operating Instructions.
6 Commissioning
6.1 Changing the battery pack
Inserting the battery pack [2 A]
Removing the battery pack[2 B]
Battery pack is ready for use immediately upon
delivery and can be charged at any time.
7 Settings
7.1 Changing direction of rotation [1-3]
• Switch to the left = clockwise rotation
• Switch to the right = counterclockwise rotation
8 Tool holder, attachments
8.1 Bit holder
The bit holder is used for fast replacement of bits.
Cordless drywall screwdriver DWC18-2500 DWC18-4500
Motor voltage 18 V 18 V
Idle speed* 0 - 2500 min
-1
0 - 4500 min
-1
Torque (hard / soft) 7 / 18 Nm 5 / 14 Nm
Chuck 1/4 ’’ DIN 3126 / ISO 1173 1/4 ’’ DIN 3126 / ISO 1173
Maximum workable screw length 55 mm 55 mm
Weight (without battery pack) 1,2 kg
Weight with depth stop (without battery pack) 1,3 kg
Weight with magazine attachment (without
battery pack)
1,6 kg
[1-1]
Bit store
[1-2]
On/Off switch
[1-3]
Right/left switch
[1-4]
AUTO/MAN switch
[1-5]
Depth stop
[1-6]
Bit
[1-7]
Insulated gripping surfaces (grey shaded
area)
CAUTION
Risk of injury
Always switch off the power tool before adjusting
settings!
WARNING
Risk of injury
Always disconnect the battery pack before per-
forming any type of work on the machine!
