3 Product Overview
Table 3.1 Technical Parameters of the AN5506-01-A (Continued)
Type
Item
Description
QoS
Supports the ACL function to match traffic based
on the ACL rules.
Supports global configuration of queue priority and
flexible mapping of 802.1p values in packets.
Supports three queue scheduling modes (PQ,
WRR and PQ+WRR); supports configuring the
weight of the scheduled queue, so as to guarantee
the service quality of high-QoS services such as
video in the multi-service environment.
Network
side
interface
GPON
interface
Provides one GPON interface (SC/UPC or
SC/APC interface), supporting transmission
distance up to 20km and complying with the ITU-T
G.984 standard.
Supports Class B+, with receiving sensitivity less
than -29 dBm.
User side
interface
LAN
interface
Provides one LAN interface (RJ-45 interface),
supporting full-duplex or half-duplex and 10 / 100 /
1000 Mbit/s auto negotiation. The maximum
transmission distance is 100 m.
MAC address capacity: 1K
Table 3.2 Specifications of the AN5506-01-A6G
Type
Item
Description
Mechanical
parameters
Dimensions
25.5mm × 112mm × 112mm (height x
width x depth)
Wall mounting
hole distance
75mm
Weight About 120g
Power supply
parameters
DC
DC 12 V/0.5 A
6
