3 Product Overview
Indicator LED Description
See Table 3.4 and Table 3.5 for the description of indicator LEDs on
the AN5506-01-A.
Table 3.4 Description of Indicator LEDs on the AN5506-01-A6G
Indica-
tor LED
Meaning
Color Status
Status Description
PON
Register
status
indicator
LED
Green
ON The ONU is activated.
Blinking The ONU is being activated.
OFF The ONU is not activated.
LOS
Optical
signal
status
indicator
LED
Red
Blinking
The ONU has not received the
optical signal.
OFF
The ONU has received the
optical signal.
LAN
Ethernet
interface
status
indicator
LED
Green
ON
The interface is connected to
the user terminal and no data
are transmitted.
Blinking
The interface is transmitting /
receiving data.
OFF
The interface is not connected
to the user terminal.
Power
Power
status
indicator
LED
Green
ON
The ONU is powered on.
OFF
The ONU is not powered on.
8
