3 Product Overview
Figure 3.5 Rear Panel of the AN5506-01-B
The side panel of the AN5506-01-B is shown in Figure 3.6.
Figure 3.6 Side Panel of the AN5506-01-B
Equipment Specifications
The AN5506-01-B specifications include technical parameters and
specifications. Table 3.6 shows the technical parameters. Table 3.7
shows the specifications.
Table 3.6 Technical Parameters of the AN5506-01-B
Type
Item
Description
Service
parameters
VLAN
Supports the IEEE 802.1Q VLAN standard.
Supports joining the 802.1Q VLAN in the tag
/ untag mode.
Supports up to 4095 VLANs.
Multicast
Supports the IGMP Snooping protocol.
Supports IGMP v1/v2/v3.
Wire-speed
forwarding
Supports Layer 2 / Layer 3 wire-speed
forwarding.
11
