FiberHome AN5506-02-A User Manual

3 Product Overview
Table 3.6 Technical Parameters of the AN5506-01-B (Continued)
Type
Item
Description
Supports Class B+, with receiving sensitivity
less than -29 dBm.
User side
interface
LAN interface
Provides one LAN interface (RJ-45
interface), supporting full-duplex or half-
duplex and 10 / 100 / 1000 Mbit/s auto
negotiation. The maximum transmission
distance is 100 m.
MAC address capacity: 1K
Phone
interface
Provides one phone interface (RJ-11
interface).
Table 3.7 Specifications of the AN5506-01-B
Type
Item
Description
Mechanical
parameters
Dimensions
25.5mm × 112mm × 112mm (height x
width x depth)
Wall mounting
hole distance
75mm
Weight About 131g
Power
supply
parameters
DC DC 12 V/1 A
Power
consumption
parameters
-
＜5W
Environment
parameters
Operating
temperature
-5℃ to 45℃
Storage
temperature
-40℃ to 70℃
13

FiberHome AN5506-02-A Specifications

General

Brand	FiberHome
Model	AN5506-02-A
Category	Modem
Language	English
