4 Web Configuration Guide
Figure 4.9 DHCP Server
2. Configure the DHCP server parameters as required. Table 4.4
describes the parameters.
3. Click Apply to save the configuration information. The
configuration will take effect after the ONU is rebooted.
Table 4.4 Parameters for the DHCP Server
Item
Description
Type
Enables or disables the DHCP server.
u Server: Enables the DHCP server. The ONU can
dynamically distribute IP addresses to user terminals.
u Disable: The user terminals connected to the ONU
cannot obtain the private network IP address using the
DHCP.
DHCP Start
IP
The starting IP address of the IP
address pool of the DHCP
server.
Note: The IP address set
here should be in the
same network segment
with the IP address set
in LAN Setting;
otherwise, the DHCP
server will not operate
normally.
DHCP End
IP
The end IP address of the IP
address pool of the DHCP
server.
42
