13.Battery charging port
(located below the saddle)
13
14.On/Off button
( Once it's on, the tail light will turn on as well.)
14
1.Brake power off system
2.Light/horn button
3.Horn
4.Power on/off button
5.Power adjustment
6.Thumb shifter
7.Power off brake
8.Throttle
9.Battery Level
10.Speed
11.Electric assist gear
12.Odometer
(Note: When not used for 10 minutes, the bike is shut down automatically when the bike is stationary.)
15 16
L R
17
R
Use a 15mm spanner to screw the pedal spindle into the threaded hole and tighten it in the direction of the arrow (left counterclockwise, right and clockwise, as shown).
(Note:When installing the pedal, be aware of the left and right, align the installation horizontally to prevent 6.the pedal from slipping out of the crank)
15.Pedal 16.Left 17.Right
1
3
5
7
１
2
3
4
5
10
9
6
7
8
11
12
5
