FIMI X8 MINI Quick Start Manual

3 Propeller
Please install and remove the propellers as the picture shown.
The propellers need to be installed according to the marks on the arms and
propellers, and distinguished the forward and reverse propellers (the attached
picture shows the forward propeller.)
Need to use a screwdriver for installation and make sure the screws are locked well.
To keep safe, screws should be replaced together with propellers.

FIMI X8 MINI Specifications

General

Max Flight Time	31 minutes
Camera Resolution	12 MP
Video Resolution	4K at 30fps
Max Speed	16 m/s
Max Transmission Distance	8 km
Dimensions (Folded)	145 x 85 x 56 mm
Dimensions (Unfolded)	200 x 145 x 56 mm
Max Ascent Speed	5 m/s
Max Descent Speed	3.5 m/s
Positioning	GPS + GLONASS
Aperture	f/2.0
ISO Range	100-3200
Gimbal	3-axis
Charging Time	90 minutes
Max Wind Resistance	Level 5
Operating Frequency	5.725-5.850 GHz
Obstacle Avoidance	No
Weight	258 g
Battery Capacity	2400 mAh
