FIMI X8 MINI Quick Start Manual

Record button
Dial
Shoot button
3 Shooting and recording
Press the shoot button to take a photo. A photo is taken when you hear 2 short
sounds.
Press the record button to record video. Recording starts when you hear 2 short
sounds. Press again to stop recording with 4 short sounds.
The pitch angle of the gimbal can be controlled by toggling the left dial up and down.

FIMI X8 MINI Specifications

General

Max Flight Time	31 minutes
Camera Resolution	12 MP
Video Resolution	4K at 30fps
Max Speed	16 m/s
Max Transmission Distance	8 km
Dimensions (Folded)	145 x 85 x 56 mm
Dimensions (Unfolded)	200 x 145 x 56 mm
Max Ascent Speed	5 m/s
Max Descent Speed	3.5 m/s
Positioning	GPS + GLONASS
Aperture	f/2.0
ISO Range	100-3200
Gimbal	3-axis
Charging Time	90 minutes
Max Wind Resistance	Level 5
Operating Frequency	5.725-5.850 GHz
Obstacle Avoidance	No
Weight	258 g
Battery Capacity	2400 mAh
