Step 4
Setting Up Data Communication
(Skip this step if you are using USB ash disk to transfer data)
The data communication ports are positioned at the rear of the
terminals, please refer to the diagrams shown on Step 3 to deter-
mine the wiring. Plug the communication jacks (TCP/IP, RS232 or
RS485) to the corresponding ports.
TCP/IP – LAN Connection
For TCP/IP connection, plug the special RJ45 jack into the TCP/IP
(LAN) Port of the terminal. Connect the other end (normal RJ45
jack) to the local area network hub or a PC. Configure the device
ID, IP address, subnet mask and Gateway in the terminal (refer to
the hardware user manual for details).
RS232 – Serial Port Connection
Plug the communication jack that is provided in the package to
connect to the communication port of the terminal. Select wires
with label RX, TX and GND, and connect the other end of these
wires to a DB9 female connector. Configure the device ID and
baudrate of the terminal (refer to the hardware user manual for
details). Use the normal RS232 cable to plug into the RS232 port
of the terminal.
Other Accessories
FingerTec offers complementing accessories which can be used with
your terminals. These optional accessories are available at
http://accessory.fingertec.com
AdapTec Plus
The AdapTec Plus is a 12VDC power supply inclusive of a 110~
240VAC switching linear power. The AdapTec Plus supplies 12VDC
power to the FingerTec terminal and door lock system as well
as charges a 12VDC 7.0Ah backup battery simultaneously. Dur-
ing an event of a power failure, the back up battery automati-cally
provides power to the terminal and maintains the door lock system.
The AdapTec Plus also prevents a secured door from being opened if it
has been tampered with.
Enclosures
An acrylic-made enclosure that protects your terminal from the risk of
meddling by unauthorized individuals. Our custom made enclosure are
specially designed to fit your terminal perfectly with specific openings
for fingerprint scanner and buttons. Our enclosure can be used to miti-
gate surrounding mild environmental hazards and help lengthen the
lifespan of the terminals. However, do note that the enclosure is not
dust-resistant and waterproof if subjected to extreme weather condi-
tions.
Door Lock Accessories
FingerTec offers various door locks accessories to complement
FingerTec door access product range.
Step 5
Finalizing the Installation
1. Check that all cable connections are done correctly.
2. Attach the terminal to the corresponding back plates and
tighten the screws to secure the terminal on the wall.
3. Switch on the power to the terminal.
4. Start using the terminal.
