English - 6 -
Connections
NOTE: When connecting a device via the YPbPr or Side AV inputs, you must use the connection cables to enable
connection(not supplied). See the illustrations above. | To enable PC audio, you will need to use an Audio cable(not supplied).
| If an external device is connected via the SCART socket, the TV will automatically switch to AV mode.| When receiving DTV
channels (Mpeg4 H.264) or while in Media Browser mode, output will not be available via the scart socket. | When using the
wall mounting kit (optional), we recommend that you plug all your cables into the back of the TV before mounting on the wall.
| Insert or remove the CI module only when the TV is SWITCHED OFF. You should refer to the module instruction manual
for details of the settings.
