BB1216 - BB1222 MU0518 Rev. A
39
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
FLOOR AND FEED ROLL PARTS
Ref. No. Part Number Description No. Req'd
1 052500 Feed Roll Hydraulic Motor 1
2 045031 Feed Roll Mount Hub 1
3 052676 Feed Roll 1
4 052517-01 Left-Hand Feeder Panel 1
5 F916-0004 Feeder Top Cover 1
6 052517-02 Right-Hand Feeder Panel 1
7 020586 2-Bolt Feed Roll Bearing 1
8 052506-01 Top Feeder Door Hinge 1
9 F916-0006-01 Top Feeder Door 1
10 052506-02 Lower Feeder Door Hinge 1
11 F916-0006-02 Bottom Feeder Door 1
12 052502-02 Door Stiffener Strap 1
13 055586 Feeder Door Pull Handle 1
14 052703 Swing Bolt 2
15 052699 Black Knob 2
16 052999 Rear Gate 1
17 052372-01 Rear Gate Seal 1
18 052372-02 Rear Gate Seal Strap 1
19 045019 Rear Floor Bearing 1
20 052224 Rear Floor Sprocket 2
21 052986 Rear Floor Drive Shaft 1
22 053023 Steel 2 Piece Coupling 1
23 052989 Floor Gear Box 1
24 052990 Hyd Motor - Floor 1
055517 Floor Motor Gasket 1 per
F816-0023 Floor Motor Shim As Needed
25 F916-0001-07 Left-Hand Gate Rail 1
26 F916-0001-08 Right-Hand Gate Rail 1
27 052985 Gate Hydraulic Cylinder 1
28 052220 Take-up Bearing 2
29 052780 Bearing Frame 2
30 052780-06 Adjustment Rod 2
31 075218 Front Idler Sprocket 4
32 052507-02 Front Idler Shaft 2
33 F916-0045 Front Clean-out Frame 1
34 052352-08 Front Clean-Out Door Rod 1
36 052821 Front Clean-Out Door 1
NOT SHOWN
053054-01 Front Floor Seal 1
053057-08 Engine Wiring Harness 1
052996 Floor Assembly 1
052872-RK Link and Pin Kit 1
F1216-0007 Floor Gear Box Mounting Plate 1
F1216-001 Floor Gear Box Horizontal Bracket 1
052780-09 Hex Jam Stop Nut, NSF 1/8 In. 2
