BB1216 - BB1222 MU0518 Rev. A
45
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
ENGINE SHEET METAL
Ref. No. Part Number Description No. Req'd
1 055669 Lock Positioning Hinge 2
2 F260-0006-02 Radiator Cap Cover 2
3 F260-0006-03 Hinge Spacer 2
4 F1216-0027 Radiator Shroud 1
5 F1216-0012 Radiator Screen 1
6 F1216-0031-01 Left Radiator Shroud Mount 1
7 F1216-0031-02 Right Radiator Shroud Mount 1
8 F1216-0030 Engine Exhaust Cover 1
9 F170-0020 Radiator Pan 1
10 012753 Front Engine Foot 2
11 052397 Rear Engine Foot 2
12 007433 Rubber Shock Mount 6
13 007887 Snubbing Washer 4
14 008664 Rear Panel Mount 2
15 F1216-0028 Rear Engine Panel 1
16 F1216-0029 Engine Top Cover 1
NOT SHOWN
053033 Hose Reel Control Button Bracket 1
