BB1216 - BB1222 MU0518 Rev. A
55
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
HYDRAULIC SYSTEM
Ref. No. Part Number Description No. Req'd
43 053015-09 3/8 in. 100R17 Hose w/ #6 1
44 053045-03 3/4 in. 100R17 Hose w/ #12 1
45 053045-04 3/8 in. 100R17 Hose w/ #6 2
46 053045-05 3/8 in. 100R17 Hose w/ #6 1
47 053045-06 3/8 in. 100R17 Hose w/ #6 1
48 053045-07 1/2 in. 100R17 Hose w/ #8 1
49 053045-08 3/8 in. 100R17 Hose w/ #6 1
50 053045-10 1/4 in. 100R17 Hose w/ #4 2
51 053079-02 3/4 in. 100R17 Hose w/ #12 1
52 053079-01 3/4 in. 300 psi Hose w/ #12 1
53 053161-03 1-1/4 in. 100R4 Hose w/ #20 1
54 053015-01 1 in. 100R1 Hose w/ #16 1
55 008702 Hydac Low Pressure Filter Assembly 1
56 A0916-001 Return Filter Breather, 10 micron 1
57 A0948-001 RB2 Filler Cap, Snap Ring, Strainer Basket 1
58 013192 AKG DC16S-12-TC115 Heat Exchanger 1
59 052500 Char-lynn Hyd Motor #104-1009 1
60 052535 Eaton Hyd. Motor #104-1021-006 1
61 052990 Char-Lynn Motor 104-1017-006 1
62 052991 Char-Lynn Motor 104-1032-006 1
63 A0915-001 Hydraulic Reservior 1
64 053077 Hydac Filter Assembly #02071996 1
65 052817 Eaton Hydraulic Pump 1
66 053086 Custom Manifold 1
67 070122 1/2 NPT Ball Valve 1
68 070660 Hydraulic Motor 104-1028-006 1
69 080329 Hydraulic Level Gauge 1
053148 SS Tubing Kit BB1216/22
70 053148-01 Tubing 1 OD X .049 Wall SS 1
71 053166-P Steel Line 1
NOT SHOWN
A0946-003 Cleanout Cover, 10 in. 1
053083 Hydraulic Filter Mounting Bracket 1
053156 Load Sense Orifice 1
